Grader Prism REVO360MC
  • Leaflet

R-360MCG

360° PRISM FOR MACHINE CONTROL SYSTEM

For machine control system with motor grader.

  • View from bottom



  • ROBUST STRUCTURE

    The core axis made by SCM435* and metal frame bring robustness against strong vibration from heavy construction equipment.

    *SCM435 : Chrome-molybdenum steel

  • REPLACEABLE PRISM

    Each prism is independent and non-glued. In case the prism is broken, it is replaceable at a minimum loss.

  • STRONG BEAM REFLECTION

    Seamlessly connected 6 prisms make strong beam reflection.
    Catch the beam from total station and reduce the lost.

SPECIFICATIONS

Prism constant -5mm
Prism height 50mm
Targetable angle H : 360°  V : ±30°
Screw 5/8-11 UNC female(bottom)
Screw depth 18mm
Dimensions W84 × D84 × H90mm
Weight 450g

STANDARD ACCESSORIES

  • ⋅Case
  • ⋅Manual
PRODUCT NAMEMODELPKG QTYMOQCODE NO.C/O
Grader Prism REVO360MC R-360MCG 1 10 225317 JP
Case for R-360MCG R-360MCG-C 1 1 225349 CN
